Omron R88D-GT series User Manual

3-103
3-5 Servo Relay Units and Cable Specifications
3
Specifications
 XW2B-20J6-8A
This Servo Relay Unit connects to the following OMRON Programmable Controllers.
Dimensions
• Terminal Block pitch: 7.62 mm.
• CJ1M-CPU21/-CPU22/-CPU23 (for 1 axis)
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
29.5
7
3.5
7
3.5135
15.5
45
20.5
42.8
2
0
10
9
19
CJ1M-CPU21/22/23 connector Servo Drive connector
(46)
Two, 3.5 dia.
