Omron R88D-GT series User Manual

3-118
3-5 Servo Relay Units and Cable Specifications
3
Specifications
 Position Control Unit Cable (XW2Z-@J-A7)
This Cable connects a Position Control Unit (C1W-NC213 or CS1W-NC413) to a Servo Relay Unit
(XW2B-40J6-2B).
Cable Models
Connection Configuration and Dimensions
Wiring
Model Length (L) Outer diameter of sheath Weight
XW2Z-050J-A7 50 cm
10.0 dia.
Approx. 0.1 kg
XW2Z-100J-A7 1 m Approx. 0.2 kg
48
L647
83
t = 11
Position Control Unit
CS1W-NC213
CS1W-NC413
Ser
vo Relay Unit
XW2B-40J6-2B
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
No.
A1/B1
A2/B2
A8
A6
A10
A14
A16
A24/B24
A19
A21
A12
A23
A22
A20/B20
B8
B6
B10
B14
B16
B23
B22
B21
B19
B12
Servo Relay Unit
Cable: AWG28 × 6P + AWG28 × 16C
Position Control Unit
Crimp terminal
