3-129
3-6 Parameter Unit Specifications
3
Specifications
3-6 Parameter Unit Specifications
R88A-PR02G Hand-held Parameter Unit
The Parameter Unit is required to operate the Servo Drive from a distance away from the Servo
Drive, or to operate and monitor the Servo Drive from a control panel. The cable connected to the
Parameter Unit is 1.5 m long.
General Specifications
Performance Specifications
Item Specifications
Ambient operating
temperature and humidity
0 to 55°C, 90% RH max. (with no condensation)
Ambient storage
temperature and humidity
−20 to 80°C, 90% RH max. (with no condensation)
Operating and storage
atmosphere
No corrosive gases
Vibration resistance 5.9 m/s
2
max.
Item Specifications
Type Hand-held
Cable length 1.5 m
Connectors Mini DIN 8-pin MD connector
Display 7-segment LED
Dimensions 62 (W) × 114 (H) × 15 (D) mm
Weight Approx. 0.1 kg (including cable)
Communications specifications
Standard RS-232
Communications method Asynchronous (ASYNC)
Baud rate 9,600 bps
Start bits 1 bit
Data 8 bits
Parity None
Stop bits 1 bit
