Omron R88D-GT series User Manual

3-97
3-4 Cable and Connector Specifications
3
Specifications
XW2B-50G5 (M3.5 Screw Terminal Block)
• Dimensions
• When using crimp terminals, use crimp terminals with the following
dimensions.
• When connecting wires and crimp terminals to a terminal block, tighten
them with a tightening torque of 0.59 N·m.
Applicable Crimp Terminals Applicable Wires
Round Crimp Terminals
1.25-3
AWG22-16
(0.3 to 1.25 mm
2
)
2-3.5
AWG16-14
(1.25 to 2.0 mm
2
)
Fork Terminals
1.25Y-3
AWG22-16
(0.3 to 1.25 mm
2
)
2-3.5
AWG16-14
(1.25 to 2.0 mm
2
)
3.5
15.5
45
7
7.3
8.5
7
29.5
3.5
43.5
20.5
247.5
Flat cable connector (MIL plug)
Terminal
block
Two,
3.5 dia.
(45.3)
Precautions
for Correct Use
Round Crimp Terminals
Fork Terminals
6.8 mm max.
3.7 mm
3.7-mm dia.
6.8 mm max.
