7-4 Disabling the Automatic Gain Adjustment Function
7
Adjustment Functions
Disabling the Adaptive Filter
The adaptive filter function, which performs automatic tracking in response to the load resonance,
can be disabled by setting the Adaptive Filter Selection (Pn23) to 0. If the adaptive filter is disabled
when it is correctly operating, suppressed resonance will become apparent, and noise or vibration
may occur. Therefore, before disabling the adaptive filter, perform copying function to the Notch
Filter 1 Frequency (Pn1D) of the Adaptive Filter Table Number Display (Pn2F) from the Fit Gain
Window on the front panel (refer to Front Panel Display Example on page 7-9) or manually set the
Notch Filter 1 Frequency (Pn1D) based on the Adaptive Filter Table Number Display (Pn2F) in the
following tables.
• Set the Notch Filter 1 Frequency (Pn1D) to 1,500 when disabling the adaptive filter using the above table.
Pn2F Notch Filter 1 Frequency (Hz) Pn2F Notch Filter 1 Frequency (Hz) Pn2F Notch Filter 1 Frequency (Hz)
0 (Disabled) 22 766 44 326
1 (Disabled) 23 737 45 314
2 (Disabled) 24 709 46 302
3 (Disabled) 25 682 47 290
4 (Disabled) 26 656 48 279
5 1482 27 631 49 269 (Disabled when Pn22 ≥ F)
6 1426 28 607 50 258 (Disabled when Pn22 ≥ F)
7 1372 29 584 51 248 (Disabled when Pn22 ≥ F)
8 1319 30 562 52 239 (Disabled when Pn22 ≥ F)
9 1269 31 540 53 230 (Disabled when Pn22 ≥ F)
10 1221 32 520 54 221 (Disabled when Pn22 ≥ E)
11 1174 33 500 55 213 (Disabled when Pn22 ≥ E)
12 1130 34 481 56 205 (Disabled when Pn22 ≥ E)
13 1087 35 462 57 197 (Disabled when Pn22 ≥ E)
14 1045 36 445 58 189 (Disabled when Pn22 ≥ E)
15 1005 37 428 59 182 (Disabled when Pn22 ≥ D)
16 967 38 412 60 (Disabled)
17 930 39 396 61 (Disabled)
18 895 40 381 62 (Disabled)
19 861 41 366 63 (Disabled)
20 828 42 352 64 (Disabled)
21 796 43 339
