2-25
2-2 External and Mounting Hole Dimensions
2
Standard Models and Dimensions
2-2 External and Mounting Hole
Dimensions
Servo Drives
Single-phase 100 VAC: R88D-GTA5L/-GT01L (50 to 100 W)
Single-phase 200 VAC: R88D-GT01H/-GT02H (50 to 200 W)
Wall Mounting
External Dimensions Mounting Hole Dimensions
UNIT No.
AC SERVO DRIVER
DATA
IM SP G
130
4
7040
28
±0.5
6
40
Two, M4
140
150
5
