Omron R88D-GT series User Manual

3-119
3-5 Servo Relay Units and Cable Specifications
3
Specifications
 Position Control Unit Cable (XW2Z-@J-A10)
This Cable connects a Position Control Unit (CS1W-NC133) to a Servo Relay Unit (XW2B-20J6-
1B).
Cable Models
Connection Configuration and Dimensions
Wiring
Model Length (L) Outer diameter of sheath Weight
XW2Z-050J-A10 50 cm
10.0 dia.
Approx. 0.1 kg
XW2Z-100J-A10 1 m Approx. 0.2 kg
48
L647
83
t = 11
1000
Position Control Unit
CS1W-NC133
Servo Relay Unit
XW2B-20J6-1B
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
26
No.
A1
A2
A7
A8
A5
A6
A10
A24
A12
A16
A14
A21
A23
24
25
A20
A19
A22
A3
A4
Servo Relay Unit
Cable: AWG28 × 4P + AWG28 × 10C
Position Control Unit
Crimp terminal
AWG20, black
AWG20, red
