Raymarine LIGHTHOUSE 3 User Manual

•M-Seriescamera(M100
,M200andM300Series)
•M100/M200-SeriescamerasrequireLightHouse™softwareversion3.9orlater.
•M300-SeriescamerasrequireLightHouse™softwareversion3.10.71orlater.
Important:
CamerasutilizingClearCruise™A
ugmentedRealityaresubjecttoanunstableimageonrough
waters.
Note:ClearCruise ’sperformanceisdependentonenvironmentalconditionsandisnota
replacementformaintainingavisualwatch.
17 .2Camerasetup
BeforeusingtheAugmentedRealityfeatures,it’simportanttocorrectlyinstallandsetupyour
compatiblecamera.
Refertoyourcamera’sinstallationmanualtodeterminethecorrectphysicalinstallationand
connectionsforusingthecameraaspartofanAugmentedRealitysystem.
Anumberofadditionalcamera-relatedsettingsandcalibrationsmustbecompletedintheVideoapp
beforeAugmentedRealityfeaturescanbeused:
•Cameraheightabovethewaterline.
•Cameradirection.
•Camerahorizontalfieldofview[notrequiredforcameraswhichautoassigntheirfieldofview].
•Horizoncalibration.
Note:
•Thecamera ’sheightabovethewaterlineandcamera’sviewdirectionneedtobephysically
measuredforaccuratecamerainstallation.
•Thecamera’shorizontalfieldofviewcanbefoundinyourcamera’sinstallationmanual
specification.
ClearCruise(ObjectDetection/VideoAnalytics,and
A ugmentedReality)
337
