UserInterfacelanguages
Thefollowinglanguagesareavailable:
Arabic(ar-AE)Bulgarian(bg-BG)Chinese(Simplified)
(zh-CN)
Chinese(T
raditional)
(zh-TW)
Croatian(hr-HR)Czech(cs-CZ)Danish(da-DK)Dutch(nl-NL)
English(en-GB)English(en-US)Estonian(et-EE)Finnish(fi-FI)
French(fr-FR)German(de-DE)Greek(el-GR)Hebrew(he-IL)
Hungarian(he-IL)Icelandic(is-IS)Indonesian(Bahasa)
(id-ID)
Italian(it-IT)
Japanese( ja-JP)Korean(ko-KR)Latvian(lv-LV)Lithuanian(lt-LT)
Malay(Bahasa)(ms-MY
ZSM)
Norwegian(nb-NO)P olish(pl-PL)Portuguese(Brazilian)
(pt-BR)
Russian(ru-RU)Slovenian(sl-SI)Spanish(es-ES)S wedish(sv-SE)
Thai(th-TH)T urkish(tr-TR)Vietnamese(vi-VN)
Boatdetails
T oensurecorrectoperationanddisplayofdatayoushouldsettheBoatDetailssettingsaccording
toyourrequirements.
Boatdetailscanbeaccessedfromthe Settingsmenu: Homescreen>Settings>BoatDetails
OptionDescription
Boat/Icon:
SelectiondeterminestheiconusedtosignifyyourvesselintheChartapp .
BoatName:
Configuresyoursystemwithyourvessel’ sname.
[Sailingonly]
Sailperformance:
SelectFix edAnglesorPolarlaylines.
[Sailingonly]
Boattype:
Selectyourvessel’ sBoattypetoprovidemoreaccurateleeway
calculations.
[Sailingonly]
[Fix edAnglesonly]
Upwindangle:
Settheangleofupwindlaylinecalculations.
[Sailingonly]
[Fix edAnglesonly]
Downwindangle:
Settheangleofdownwindlaylinecalculations.
[Sailingonly]
[P olaronly]
P olar:
SelectthePolartablethatwilldefineyourlaylinecalculation.
Minsafeheight:
Enteryourvessel’ smaximumunladenheightfromthewaterline.T oensure
adequateclearance,itisrecommendedthatyouaddasafetymarginto
thisfiguretoallowforvariationcausedbyvesselmovements.
Minsafewidth:
Enteryourvessel’ smaximumwidthatitswidestpoint.Toensureadequate
clearanceonbothsides,itisrecommendedthatyouaddasafetymargin
forportandstarboardtothisfiguretoallowforvariationcausedbyvessel
movements.
Minsafedepth:
Enteryourvessel’ smaximumdepthwhenfullyladen.Thisisthedepth
fromthewaterlinetothelowestpointonthevessel’skeel.Toensure
adequateclearance,itisrecommendedthatyouaddasafetymarginto
thisfiguretoallowforvariationcausedbyvesselmovements.
Numofengines:
Selectthenumberofenginesonyourvessel.Whenconnectedtoa
compatiblesystem,yourMFDcanmonitorenginedata.
Identifyengines:Onceyouhaveselectedthenumberofengines,select Identifyengines
andfollowtheonscreeninstructionstoconfigureyourengines.May
requireane
xtrahardwareinterfacetoenableenginedatatobedisplayed.
Homescreen85
