You can use the DEL button to erase a connection at the cursor or arrow
position. Where connections intersect, the vertical connections are
deleted first, then, if you press the DEL button again, the horizontal con-
nections are deleted.
Press the cursor button once more.
The cursor will move to the coil field.
Press the OK button.
The specified coil function and the output relay Q001 are correct and do not have to
be changed.
Your result will look as follows: Your first wired and functional circuit diagram
I001---I002---------Ä Q001
L:1 C:5 40120
Figure 58: Completed circuit diagram
You can use the cursor buttons to access the part that is not visible.
Press the ESC button to leave the circuit diagram display.
Line 6 will show the SAVE menu option.
Saving
I001---I002--------------Ä Q001
SAVE
Figure 59: SAVE menu option in the status line
Press the OK button to confirm.
The circuit diagram is stored.
Press the ESC button twice to return to the main menu.
You can test the circuit diagram if the S1 and S2 buttons are connected.
