2. Installation
2.1 Prerequisites for the location of use
l Do not remove safety measures at switching points until you get the all-clear for the
areas where work was performed
l If carrying out work that involves more than one worker, make absolutely sure that
nobody is still in the danger zone
2.1 Prerequisites for the location of use
The device must be used exclusively in locations for which it has been approved/cer-
tified.
The supply voltage must be guaranteed and must conform to the relevant spe-
cifications-
→ Section "Nameplate", page 25and
refer to the specifications on the → Section "Technical data", page 584 of the indi-
vidual devices, → page 584
CAUTION
INSTALLATION CUT-OUT
The mounting cutout must be located in a position that will not defeat the
purpose of stabilizing webs or other reinforcing elements in the control
panel. If necessary, reinforcing elements must be installed/added.
2.1.1 Installation position
easyE4 devices are intended to be flush mounted in control cabinets, control panels, ser-
vice distribution boards, or control consoles from behind.
The following must be taken into account when selecting the installation position:
l The controls and connectors must remain accessible even after the device has
been installed.
l easyE4 devices can be installed in a horizontal or vertical position.
The slot for the microSD memory card is located under a cover on
the base device.
Please observe the clearance required in order to be able to remove
the microSD and use the buttons.
2.1.1.1 Temperatures
Make sure that the device does not overheat.
Do not expose the device to direct sunlight or other sources of heat.
The minimum clearance to components that radiate heat, such as transformers under
heavy loads, is 15 cm.
38
easyE4 11/18 MN050009 EN www.eaton.com
