Eaton easyE4 series User Manual

6. Function blocks
6.1 Manufacturer function blocks
You can assign the following operands to the function block inputs that are bit inputs:
Operands Bit inputs
Constant 0, constant 1 x
M – Markers x
RN - Input bit via NET x
SN - Output bit via NET (send) x
N - Net marker bit x
nN - NET marker bit NET station n x
ID: Diagnostic alarm x
LE - Output backlight x
P buttons x
I - Bit input x
Q - Bit output x
Q - Bit output of a FB x
Operating modes
Description Note
INI Initialize Initializes the destination range with a
byte value that is stored at the source
address. The length of the source range
is fixed at one byte. NO defines the length
of the destination range.
CPY Copy Copies a data block from a source to a
destination range. NO defines the size of
the data block to be copied.
Copy mode, operating mode = CPY
In Copy mode, the function block copies the complete data range of the size specified at
NO from the source range to the destination range. You specify the start of the source
range and the destination range via I1 (source address) and I2 (destination address).
Example transfer with offset
Copying a marker data block (2 bytes) with a variable offset definition for the marker
ranges.
The content of the marker bytes MB14 + MB15 are to be copied with a variable offset
that is defined via the output QV of counter relay C3.
I1 NU14
I2 C 3
NO
NU 2
Initialization mode, operating mode = INI
In initialization mode, the function block takes a byte value that is stored at the source
address (input I1) and copies it to a destination range. The destination range is specified
easyE4 11/18 MN050009 EN www.eaton.com
313
