Eaton easyE4 series User Manual

6. Function blocks
6.1 Manufacturer function blocks
Tangent
The output value is based on the following equation:
Y(t) = [T
A
/T
G
] ∙ [ K
P
∙ ( X(t)-Y(t-1) ) ]
Y(t) = Calculated output value at time t
T
A
=Scan time (calculated internally)
T
G
= Recovery time
K
P
= Proportional gain
X(t) = Actual value at time t
Y(t-1) = Calculated output value at time t-1
Scan time
Scan time T
A
depends on the set recovery time value.
At recovery time T
G
Internal calculation of
the scan time T
A
T
G
≦ 1000 ms T
A
= 10 ms
T
G
> 1000 ms T
A
= T
G
/100
Cycle time to scan time
The ratio of cycle time
cyc
to sampling time T
A
should be such that the sampling time is
much larger than the cycle time (by a factor of approximately 10): T
A
=10 ∙ t
cyc
. The
sample time is set indirectly with the value for recovery time T
G
(please refer to the
table above).
The following therefore applies: t
cyc
<< T
A
.
For applications in which this cannot be fulfilled, the cycle time should be set with the
ST (set cycle time) function block so that the scan time is an integral multiple of the
cycle time.
t
cyc
∙ n = T
A
mit n = 1,2,3, …
The function block always works with a scan time that is an integral multiple of the
cycle time. This can cause the set recovery time to be lengthened.
In the case of time-consuming application scenarios in which,
for instance, a signal smoothing filter and a PID controller are
used and visualization tasks need to be executed sim-
ultaneously, the cycle time may be extended to an extent that
may not be tolerable for controller tasks. In these kinds of
applications, move the time-consuming calculations to a
second device connected via easyNet – please refer to
280
easyE4 11/18 MN050009 EN www.eaton.com
