1. easyE4 control relays description
1.5 What the different parts of the part number mean
1.5 What the different parts of the part number mean
The part number includes information that specifies the version and model of the spe-
cific device being used.
The Part number can be found at the front of the easyE4.
easy-E4 - .C - .. ... - x1(P)
Power
rating
Type of
supply
voltage
Number
of input-
s/outputs
Type of output
R-Relay
T-Transistor
A-Analog
E-Expansion
CX-Base device with LED dia-
gnostics
C-Base device with display and
buttons
1-Version
P-Model with push-in terminals
instead of screw terminals
Table 2: Part number for screw terminal devices
Make sure to take advantage of the EATON online catalog. Enter "easy" into the search
box and the catalog will take you directly to the corresponding product group in the
Automation, Control and visualization section.
http://www.eaton.eu/ecat
1.6 Nameplate
The device can be identified by checking the nameplate on its side.
This nameplate includes the following information:
l Manufacturer
l Operational voltage
l Heat dissipation information
l Type approval and certification marks and information
l Information relevant to UL listing
In addition to the device's part number and MAC address, the QR code in the front also
contains additional information:
l Version
l Serial number
l Production Date
l Delivered operating system
