Eaton easyE4 series User Manual

2. Installation
2.4 Connection terminals
2.4.8 Terminal configurations for individual devices
EASY-E4-UC-12RC1, EASY-E4-UC-12RCX1
Power Supply +UC 0V 0V
Input I1 I2 I3 I4 I5 I6 I7 I8
Output Q1/1 Q1/2 Q2/1 Q2/2 Q3/1 Q3/2 Q4/1 Q4/2
EASY-E4-DC-12TC1, EASY-E4-DC-12TCX1
Power Supply +24V 0V 0V
Input I1 I2 I3 I4 I5 I6 I7 I8
Output power supply +24VQ +24VQ 0V 0V
Output Q1 Q2 Q3 Q4
EASY-E4-UC-16RE1
Power Supply +UC 0V 0V
Input I1 I2 I3 I4 I5 I6 I7 I8
Output Q1/1 Q1/2 Q2/1 Q2/2 Q3/1 Q3/2 Q4/1 Q4/2
Output Q5/1 Q5/2 Q6/1 Q6/2 Q7/1 Q7/2 Q8/1 Q8/2
EASY-E4-UC-8RE1
Power Supply +UC 0V
Input I1 I2 I3 I4
Output Q1/1 Q1/2 Q2/1 Q2/2
Output Q3/1 Q3/2 Q4/1 Q4/2
EASY-E4-DC-16TE1
Power Supply +24V 0V 0V
Input I1 I2 I3 I4 I5 I6 I7 I8
Output Q1 Q2 Q3 Q4 Q5 Q6 Q7 Q8
EASY-E4-DC-8TE1
Power Supply +24V 0V
Input I1 I2 I3 I4
Output Q1 Q2 Q3 Q4
EASY-E4-DC-6AE1
Power Supply +24V 0V
Input IA1 GND IA2 GND
Output IA3 GND IA4 GND
Output QA1 GND QA2 GND
60
easyE4 11/18 MN050009 EN www.eaton.com
