142 smart.Turn Units
2.11 Units—Special Operations
"Program end" unit
In every smart.Turn program, the end unit should be called once at the
end of the machining section.
Unit name: END / Called cycle: None
"Program end" form
ME Type of return jump
30: Without M30 restart
99: With M99 restart
NS Block number for return jump
G14 Tool change point
No axis (do not approach the tool change point)
0: Simultaneous (X and Z axes depart diagonally)
1: First X, then Z
2: First Z, then X
3: Only X
4: Only Z
5: Only Y
6: Simultaneous with Y
MFS M command at the start of the unit
MFE M command at the end of the unit
