316 ISO Programming
4.26 Milling Cycles
4.26 Milling Cycles
Overview of milling cycles
G791 Linear slot on the face. The position and length of the slot are
defined directly in the cycle; slot width = cutter diameter: Page 317
G792 Linear slot on the lateral surface. The position and length of
the slot are defined directly in the cycle; slot width = cutter
diameter: Page 318
G793 Contour and figure milling cycle on the face. The contour is
described directly after the cycle and concluded by G80
(compatibility cycle MANUALplus 4110): Page 319
G794 Contour and figure milling cycle on the lateral surface. The
contour is described directly after the cycle and concluded by G80
(compatibility cycle MANUALplus 4110): Page 321
G797 Face milling. Mills figures (circles, polygons, individual
surfaces, contours) as islands on the face: Page 324
G798 Helical slot milling. Mills a helical slot on the lateral surface,
slot width = cutter diameter: Page 326
G840 Contour milling. Mills ICP contours and figures. Closed
contours are machined inside/outside of the contour, or on the
contour. Open contours are machined from the left/right of the
contour, or on the contour. G840 is used on the face and lateral
surface: Page 327
G845 Pocket milling—roughing. Roughs out closed ICP contours
and figures on the face and lateral surface: Page 337
G846 Pocket milling—finishing. Finishes closed ICP contours and
figures on the face and lateral surface: Page 343
Contour definitions in the MACHINING section (figures)
Face
G301 Linear slot: Page 211
G302/G303 Circular slot: Page 211
G304 Full circle: Page 212
G305 Rectangle: Page 212
G307 Eccentric polygon: Page 213
Lateral surface
G311 Linear slot: Page 220
G312/G313 Circular slot: Page 220
G314 Full circle: Page 221
G315 Rectangle: Page 221
G317 Eccentric polygon: Page 222
