Page #244 background imageLoading...
Page #244 background image
244 ISO Programming
4.16 Tools, Compensations
Additive compensation G149
The MANUALplus manages 16 tool-independent compensation
values. One G149 followed by a D number activates the additive
compensation function. G149 D900 deactivates the additive
compensation function. The compensation values are managed in the
Program Run mode (see “Program Run mode” in the MANUALplus
620 User's Manual).
Programming:
The compensation becomes effective after the tool has moved in
the compensation direction by the compensation value. Therefore,
program G149 one block before the block containing the path of
traverse to which the compensation is to apply.
Additive compensation remains in effect up to:
the next G149 D900
the next tool change
program end
Example: G149
. . .
N1 T3 G96 S200 G95 F0.4 M4
N2 G0 X62 Z2
N3 G89
N4 G42
N5 G0 X27 Z0
N6 G1 X30 Z-1.5
N7 G1 Z-25
N8 G149 D901 [activate compensation]
N9 G1 X40 BR-1
N10 G1 Z-50
N11 G149 D902
N12 G1 X50 BR-1
N13 G1 Z-75
N14 G149 D900 [deactivate compensation]
N15 G1 X60 B-1
N16 G1 Z-80
N17 G1 X62
N18 G80
. . .
Parameters
D Additive compensation (default: D900):
D900: deactivates the additive compensation
D901 to D916: activates the additive compensation
The additive compensation is added to the tool
compensation.
