HEIDENHAIN MANUALPLUS 620 User Manual

292 ISO Programming
4.22 Drilling and Boring Cycles
4.22 Drilling and Boring Cycles
Overview of drilling and boring cycles and
contour reference
The drilling and boring cycles can be used with driven or stationary
tools.
Drilling and boring cycles:
 G71 Simple drilling: Page 293
 G72 Boring/countersinking (only with contour reference (ID / NS) -
Page 295
 G73 Tapping (not with G743—G746): Page 302
 G74 Deep-hole drilling: Page 299
 G36 Tapping—single path (direct position input): Page 298
 G799 Thread milling (direct position input): Page 306
Pattern definitions:
 G743 Linear pattern on face for drilling and milling cycles: Page 302
 G744 Linear pattern on lateral surface for drilling and milling
cycles: Page 304
 G745 Circular pattern on face for drilling and milling
cycles: Page 303
 G746 Circular pattern on lateral surface for drilling and milling
cycles: Page 305
Possibilities of defining a contour reference:
 Path definition directly in the cycle.
 Reference to a hole or pattern definition in the contour section (ID,
NS) for machining on the front face or lateral surface.
 Centric hole in the turning contour (G49): Page 197
 Pattern definition in the block before the cycle call (G743 - G746)
