384 ISO Programming
4.37 Connection between Geometry and Machining Commands
C-axis machining—front/rear face
C-axis machining—lateral surface
Function Geometry Machining
Individual elements  G100 to G103  G840 Contour milling
 G845/G846 Pocket milling, roughing/finishing
Figures  G301 Linear slot
 G302/G303 Circular slot
 G304 Full circle
 G305 Rectangle
 G307 Eccentric polygon
 G840 Contour milling
 G845/G846 Pocket milling, roughing/finishing
Hole  G300  G71 Simple drilling cycle
 G72 Counterboring, countersinking, etc.
 G73 Tapping cycle
 G74 Deep hole drilling cycle
Function Geometry Machining
Individual elements  G110 to G113  G840 Contour milling
 G845/G846 Pocket milling, roughing/finishing
Figures  G311 Linear slot
 G312/G313 Circular slot
 G314 Full circle
 G315 Rectangle
 G317 Eccentric polygon
 G840 Contour milling
 G845/G846 Pocket milling, roughing/finishing
Hole  G310  G71 Simple drilling cycle
 G72 Counterboring, countersinking, etc.
 G73 Tapping cycle
 G74 Deep hole drilling cycle
