HEIDENHAIN MANUALPLUS 620 User Manual

38 NC Programming
1.3 Program Section Code
BLANK section
In this program section, you describe the contour of the workpiece
blank.
AUXIL_BLANK section
In the AUXIL_ BLANK section, you define additional workpiece blanks,
which can be activated with G702 when required.
FINISHED section
In this program section, you describe the contour of the finished part.
After the FINISHED section you use additional section codes such as
FACE, LATERAL, etc.
AUXIL_CONTOUR section
In this program section, you describe the auxiliary turning contours.
FACE, REAR sections
In this program section, you describe contours on the front or rear
face. The program section code defines the position of the contour in
Z direction.
LATERAL section
In this program section, you describe the contours on the lateral
surface. The program section defines the position of the contour in X
direction.
Parameter
Z Position of the front/rear-face contour
Parameter
X Reference diameter of lateral-surface contours.
