HEIDENHAIN MANUALPLUS 620 User Manual

442 Overview of Units
6.4 Units—”Milling in C Axis” Group
“C-axis lateral surface milling” group
Unit Description Page
G792_NUT_MANT_C G792 Linear slot
Milling a linear slot
Page 124
G792_LIN_MANT_C G792 Linear slot pattern
Milling of linear slots in a linear pattern
Page 125
G792_CIR_MANT_C G792 Circular slot pattern
Milling of linear slots in a circular pattern
Page 126
G798_Wendelnut_C G798 Helical slot milling
Milling a thread-shaped helical slot
Page 127
G840_FIG_MANT_C G840 Contour milling, figures
Milling figures inside, outside and on the contour
Page 128
G84x_FIG_MANT_C G84x Pocket milling, figures
Roughing out closed figures, inside
Page 131
G840_Kon_C_Mant G840 Contour milling, ICP
Machining ICP contours on the lateral surface inside, outside and on the contour
Page 130
G845_TAS_C_MANT G845 Pocket milling, ICP
Inside rough-out of closed ICP contours on the lateral surface
Page 133
G840_ENT_C_MANT G840 Deburring
Deburring ICP contours on the lateral surface
Page 136
G802_GRA_MANT_C G802 Engraving
Engraving characters strings on the lateral surface
Page 135
