444 Overview of Units
6.6 Units—”Milling in Y Axis” Group
6.6 Units—”Milling in Y Axis” Group
“Milling in XY plane” group
Unit Description Page
G840_Kon_Y_Stirn G840 Contour milling
Machining contours in the XY plane inside, outside and on the contour
Page 153
G845_Tas_Y_Stirn G845 Pocket milling
Inside rough-out of closed contours in the XY plane
Page 154
G840_ENT_Y_STIRN G840 Deburring
Deburring contours in the XY plane
Page 159
G801_GRA_STIRN_C G841 Single surface
Milling a single surface (flat) in the XY plane
Page 156
G840_Kon_C_STIRN G843 Centric polygon
Milling a centric polygon in the XY plane
Page 157
G803_GRA_Y_STIRN G803 Engraving
Engraving character strings in the XY plane
Page 158
G800_GEW_Y_STIRN G800 Thread milling
Milling a thread in an existing hole in the XY plane
Page 160
