Huawei SmartAX MA5600T Hardware Description

Figure 2-6 Ventilation of the MA5600T ETSI service subrack
2.2 MA5600T ETSI SPL Subrack Description
This topic provides the appearance and specifications of the ETSI SPL subrack, and describes
the structure, function, and configuration of the subrack.
2.2.1 Appearance
The ETSI SPL subrack provides 22 slots. The SPL subrack is installed in the cabinet through
the mounting brackets. This topic provides the appearance and composition of the ETSI SPL
subrack.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
2 Subrack and Chassis
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
86
