Specification H80BCVME H806CCPE H80DCCPE H80DCSPE
Power supply at
high voltage (for a
long distance)
Yes Yes Yes Yes
Port current 20 mA/25
mA/30 mA
20 mA/25
mA/30 mA
20 mA/25
mA/30 mA/35
mA/40 mA
20 mA/25
mA/30 mA/35
mA/40 mA
3.19.3 H80BCAME Board Description
H80BCAME is a 48-port ADSL2+&POTS combo board with built-in splitter, providing 48
channels of ADSL2+ and POTS access services.
Feature and Specifications
Please refer to "ADSL2&POTS Combo Board Comparison".
Technical Specifications
Please refer to "Power Consumption and Maximum Frame Size of Boards".
Working Principle
Figure 3-81 Working principle of the H80BCAME board
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
426
