Figure 5-3 Appearance of the AC power cable
Specification
Table 5-2 lists the parameters of the AC power cable.
Table 5-2 Parameters of the AC power cable
Specification
Description
Type Electric power cable
Color Black
DC resistance of the inner conductor 3.3 ohms/km
Maximum current 43 A
Cross-sectional area of the conductor
6 mm
2
5.1.4 AC Power Cable (Device)
An AC power cable is used to transmit AC power supply to loads and enable the loads to
work in the normal state.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
5 Cable
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
866
