Huawei SmartAX MA5600T Hardware Description

Indicator
Indicato
r
Name Color Status Meaning
RUN
ALM
Running
status
indicator
Red Blinking The board enters the APP
start phase during the
board startup
Green Blinking quickly (on
for 0.25 s and off for
0.25 s repeatedly)
The board enters the phase
of communication with the
control board during its
startup
Green Blinking slowly (on
for 1 s and off for 1 s
repeatedly)
The board works in the
normal state
Orange Blinking A high-temperature alarm
is generated
Red On The board is faulty
BSY Port status
indicator
Green Blinking The board carries services
- Off The board carries no
service
0, 1, 2 ... PON port
indicator
Green On The ONT of the related
PON port is online
Green Blinking The optical module does
not take effect
- Off The ONT of the related
PON port is offline
3.16 10G GPON Service Board
10G GPON service boards work with ONUs to provide 10G GPON access service.
3.16.1 10G GPON Service Board Comparison
Table 3-37 Specifications lists of 10G GPON service board
Service Board
H802XGBC H801XGBD
Number of 10G GPON ports
supported by each board
4 8
Port mode XFP SFP+
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
395
