2.5.2 Physical Specifications
This topic provides the dimensions, weight, and power consumption of the MA5603T chassis.
Dimensions and Weight
Table 2-31 Dimensions and weight of the MA5603T
Item
Specification
Dimensions (W x D x H, excluding
mounting brackets)
442.00 mm x 283.20 mm x 263.90 mm
Dimensions (W x D x H, including mounting
brackets of 19-inch standard)
482.60 mm x 283.20 mm x 263.90 mm
Dimensions (W x D x H, including mounting
brackets of ETSI standard)
535.00 mm x 283.20 mm x 263.90 mm
Weight (empty chassis) 7.00 kg
Power Supply
Table 2-32 Power specifications of the MA5603T
Item
Specification
Power supply mode DC (dual power for backup)
Rated voltage -48 V / -60 V
Working voltage range -38.4 V to -72 V
Maximum input current 20 A
Power Consumption
Table 2-33 Power consumption of the MA5603T chassis (Unit: W)
Typical
Configu
ration
Static
power
consumptio
n
Maximum
power
consumptio
n
Typical
power
consumptio
n
Board configuration
ADSL2+ 189.84 606.55 398.195 H802SCUN*2+H801X2CS
*2+H801CITD
+H801PRTE*2+H801FCBI
+H805ADPD*6
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
2 Subrack and Chassis
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
116
