Indicato
r
Name Color Status Meaning
Green Blinking quickly (on
for 0.25 s and off for
0.25 s repeatedly)
The board starts up and is
being loaded with software
- Off The board is faulty
ALM Alarm
indicator
Red On The board is faulty or its
CPLD software is being
updated
- Off The board functions
properly
LINK Link status
indicator
Green On The link is normal
- Off The link is abnormal
ACT Data status
indicator
Yellow Blinking Data is being transmitted
- Off No data is being
transmitted
3.8.7 H802GICK Board Description
The H802GICK board is a 2-port GE uplink interface card that provides two GE upstream or
cascading optical ports.
Functional Specifications
Please refer to "Upstream Interface Board Comparison".
Technical Specifications
Please refer to "Power Consumption and Maximum Frame Size of Boards".
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
272
