Pin Signal Pin Signal Port Pin Signal Pin Signal
11 A 2
6
27 A 34 43 A 42 59 A -
12 B 28 B 44 B 60 B
13 A 2
5
29 A 33 45 A 41 61 A -
14 B 30 B 46 B 62 B
15 A 2
4
31 A 32 47 A 40 63 A -
16 B 32 B 48 B 64 B
3.19.5 H80BCVME Board Description
H80BCVME is a 48-port VDSL2&POTS combo board with built-in splitter, providing 48
channels of VDSL2 and POTS access services.
Functional Specifications
Please refer to "VDSL2&POTS Combo Board Comparison".
Technical Specifications
Please refer to "Power Consumption and Maximum Frame Size of Boards".
Working Principle
Figure 3-83 Working principle of the H80BCVME board
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
437
