Huawei SmartAX MA5600T Hardware Description

Indicato
r
Name Color Status Meaning
NOTE
Only
LEDs
with the
even
IDs are
valid
when
the port
is
connect
ed to a
one-
channel
optical
module.
Green Blinking Data is being transmitted
3.18 ATM Interface Board
The ATM interface board includes H801AIUG.
3.18.1 H801AIUG Board Description
The H801AIUG board is an ATM interface init board. The board connects to the ATM-
DSLAM devices in the downstream direction, and also provides the ATM private services.
Functional Specifications
The H801AIUG board supports the following functions:
l Four ATM optical ports (STM-1)
l ATM cascading upstream transmission (ATM PWE3) through a private line
Technical Specifications
Please refer to "Power Consumption and Maximum Frame Size of Boards".
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
416
