Huawei SmartAX MA5600T Hardware Description

Table 3-64 Pin assignments of the PSTN1 port
Pin Signa
l
Pin Signa
l
Port Pin Signa
l
Pin Signa
l
64 TIP47 48 TIP39
133
3264
32 TIP48 16 TIP56
63 RING
47
47 RING
39
31 RING
48
15 RING
56
62 TIP46 46 TIP38 30 TIP49 14 TIP57
61 RING
46
45 RING
38
29 RING
49
13 RING
57
60 TIP45 44 TIP37 28 TIP50 12 TIP58
59 RING
45
43 RING
37
27 RING
50
11 RING
58
58 TIP44 42 TIP36 26 TIP51 10 TIP59
57 RING
44
41 RING
36
25 RING
51
9 RING
59
56 TIP43 40 TIP35 24 TIP52 8 TIP60
55 RING
43
39 RING
35
23 RING
52
7 RING
60
54 TIP42 38 TIP34 22 TIP53 6 TIP61
53 RING
42
37 RING
34
21 RING
53
5 RING
61
52 TIP41 36 TIP33 20 TIP54 4 TIP62
51 RING
41
35 RING
33
19 RING
54
3 RING
62
50 TIP40 34 TIP32 18 TIP55 2 TIP63
49 RING
40
33 RING
32
17 RING
55
1 RING
63
3.20.5 H809ASPB Board Description
The H809ASPB board is a 64-port VOIP subscriber board, providing 64 channels of VoIP
POTS access services.
Feature and Specifications
Please refer to "Voice Board Comparison".
Technical Specifications
Please refer to "Power Consumption and Maximum Frame Size of Boards".
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
478

Huawei SmartAX MA5600T Specifications

General

Brand	Huawei
Model	SmartAX MA5600T
Category	Control Unit
Language	English
