Name Color Status Meaning
RUN
ALM
Running
status
indicator
Red Blinking The board enters the APP
start phase during the
board startup
Green Blinking quickly (on
for 0.25 s and off for
0.25 s repeatedly)
The board enters the phase
of communication with the
control board during its
startup
Green Blinking slowly (on
for 1 s and off for 1 s
repeatedly)
The board works in the
normal state
Orange Blinking A high-temperature alarm
is generated
Red On The board is faulty
ACT Active
indicator
Green On This board is active
Yellow On This board works in the
load-balancing mode
- Off This board is standby
LINK Link status
indicator
Green On A connection is set up on
the port
- Off No connection is set up on
the port
ACT Data status
indicator
Yellow Blinking Data is being transmitted
- Off No data is being
transmitted
3.12.3 H801SPUB Board Description
The H801SPUB board is a MPLS service processing unit board.
Functional Specifications
l 10 Gbit/s MPLS switching capability
– Unidirectional 10 Gbit/s, bidirectional 5 Gbit/s when only one control board
(SCUx) is working
– Bidirectional 10 Gbit/s when two control boards (SCUx) are working in load
sharing mode (V800R011C00 and later versions)
l Active/standby switchover of the control boards
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
