Huawei SmartAX MA5600T Hardware Description

Table 3-205 Pin assignments of the PSTN port
Pin Signa
l
Pin Signa
l
Port Pin Signa
l
Pin Signa
l
64 TIP15 48 TIP7
133
3264
32 TIP16 16 TIP24
63 RING
15
47 RING
7
31 RING
16
15 RING
24
62 TIP14 46 TIP6 30 TIP17 14 TIP25
61 RING
14
45 RING
6
29 RING
17
13 RING
25
60 TIP13 44 TIP5 28 TIP18 12 TIP26
59 RING
13
43 RING
5
27 RING
18
11 RING
26
58 TIP12 42 TIP4 26 TIP19 10 TIP27
57 RING
12
41 RING
4
25 RING
19
9 RING
27
56 TIP11 40 TIP3 24 TIP20 8 TIP28
55 RING
11
39 RING
3
23 RING
20
7 RING
28
54 TIP10 38 TIP2 22 TIP21 6 TIP29
53 RING
10
37 RING
2
21 RING
21
5 RING
29
52 TIP9 36 TIP1 20 TIP22 4 TIP30
51 RING
9
35 RING
1
19 RING
22
3 RING
30
50 TIP8 34 TIP0 18 TIP23 2 TIP31
49 RING
8
33 RING
0
17 RING
23
1 RING
31
3.26.3 H801VSTL Board Description
The H801VSTL board is a 24-port VDSL2 over POTS splitter board, separating 24-channel
VDSL signals from POTS signals.
Functional Specifications
The H801VSTL board supports the following function:
l Separating 24-channel VDSL2 signals from POTS signals
l Supporting complex impedance (ETSI TS 101 952 01 01 option A)
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
808
