Board Panel
ports
Internal interfaces
Channel
to the
service
board
Channel to the GIU
board
Channel to the
standby
control board
Note
H801S
CUV
4 GE/
10GE
ports,
Support
ing
automat
ic
switchi
ng for
remote
softwar
e
commis
sioning
using
GE
upstrea
m
transmi
ssion.
16 10GE/
20GE
channels
Providing two 10GE
channels for each
upstream boards
Providing two
20GE channels
for load sharing
with the standby
H801SCUV
board
-
3.6.2 H801SCUB Board Description
The H801SCUB board is a super control unit board. It is the core of the system control and
service switching and aggregation. It can also function as the management and control core of
the network management system (NMS). The H801SCUB board communicates with service
boards about the key management and control information through the master/slave serial port
and inband GE channel. In this way, the H801SCUB configures, manages, and controls the
device. The H801SCUB also implements the simple route protocol function.
Functional Specifications
Please refer to "SCU boards Comparison".
Technical Specifications
Please refer to "Power Consumption and Maximum Frame Size of Boards".
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
202
