Huawei SmartAX MA5600T Hardware Description

Extinction Ratio 8.2 dB
Standards Compliance of the FE Optical Modules
Standard ID Description
IEEE 802.3 100BASE-BX Fast Ethernet at 100 Mbit/s
SFF-8472 Specification for Diagnostic Monitoring Interface for
Optical Transceivers
4.6 FE/GE Adaptive Optical Module
This topic describes the parameters and relation between FE/GE adaptive optical modules and
boards.
Relation between FE/GE Adaptive Optical Moduls and Boards
An FE/GE adaptive optical modules is applicable to the OPGD and OPGE boards.
Two-channel One-fiber Bi-directional FE/GE adaptive optical module
A two-channel one-fiber bi-directional FE/GE adaptive optical module is connected to two
LC optical fibers to provide two FE/GE channels.
Type
Two-channel one-fiber bi-directional optical module
No. 1 2
Operating
Wavelength
Tx: 1490 nm
Rx: 1310 nm
Tx: 1490 nm
Rx: 1310 nm
Encapsulation
Type
CSFP CSFP
Port Rate 125 Mbit/s–1.25 GBit/s 125 Mbit/s–1.25 GBit/s
Minimum
Output Optical
Power
-9.00 dBm -9.00 dBm
Maximum
Output Optical
Power
-3.00 dBm -3.00 dBm
Maximum
Receiver
Sensitivity
-23.00 dBm -24 dBm
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
4 Optical and Electrical Module
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
860
