Table 3-11 Ports of MCU boards
Board Panel ports Internal interfaces
Channel to the GIU
board
Channel to the standby
control board
H801M
CUD
4 GE ports 2 GE/10GE ports Providing one 10GE port for
load sharing with the
standby H801MCUD board
H801M
CUD1
2 GE ports and 2
GE/10 GE ports
2 GE/10GE ports Providing one 10GE port for
load sharing with the
standby H801MCUD1 board
H801M
CUE
4 GE ports 2 GE/10GE ports Providing one 10GE port for
load sharing with the
standby H801MCUE board
3.7.2 H801MCUD Board Description
The H801MCUD board is a mini control unit board. It is the core of the system control and
service switching and aggregation. The H801MCUD board can also function as the
management and control core of the integrated network management system (NMS). It
communicates with service boards about the key management and control information
through the master/slave serial port and inband GE/10GE channel. In this manner, the
H801MCUD board configures, manages, and controls the device, and also implements the
simple route protocol functions.
Functional Specifications
Please refer to "MCU boards Comparison".
Technical Specifications
Please refer to "Power Consumption and Maximum Frame Size of Boards".
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
240
