Indicato
r
Name Color Status Meaning
- Off The board functions
properly
LINK Link status
indicator
Green On The link is normal
- Off The link is abnormal
ACT Data status
indicator
Yellow Blinking Data is being transmitted
- Off No data is being
transmitted
3.8.13 H801X2CK Board Description
The H801X2CK board is a 2-port 10GE/GE uplink interface card that provides two 10GE/GE
upstream or cascading optical ports.
Functional Specifications
Please refer to "Upstream Interface Board Comparison".
Technical Specifications
Please refer to "Power Consumption and Maximum Frame Size of Boards".
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
290
