Huawei SmartAX MA5600T Hardware Description

NOTE
There are different types of 10GE CWDM optical modules, and these types of optical modules vary with
the operating wavelength.
Standards Compliance of the 10GE Optical Port
Standard ID
Description
IEEE 802.3ae 10 Gbit/s (1,250 MB/s) Ethernet over fiber
SFF-8431 Specifications for Enhanced Small Form Factor Pluggable
Module SFP+
INF-8432 Specification for SFP+ Module and Cage
4.5 FE Optical Module
This topic describes the types, specifications, and relation between FE optical modules and
boards
Relation between FE Optical Modules and Boards
Board Type
Board Name One-channel One-fiber Bi-
directional FE Optical
Module
Two-channel One-fiber Bi-
directional FE Optical
Module
P2P interface
board
OPFA √ ×
OPGD √ √
OPGE √ √
One-channel One-fiber Bi-directional FE Optical Module
A one-channel one-fiber bi-directional FE optical module is connected to one LC optical fiber
to provide one FE channel.
Type
One-channel one-fiber bi-directional optical module
No. 1 2
Operating
Wavelength
Tx: 1550 nm
Rx: 1310 nm
Tx: 1310 nm
Rx: 1550 nm
Encapsulation Type eSFP eSFP
Port Rate 155 Mbit/s 155 Mbit/s
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
4 Optical and Electrical Module
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
858
