Huawei SmartAX MA5600T Hardware Description

Table 1-1 Dimensions and weight of the N63E-22 cabinet
Specification Value
Standard compliance ETSI cabinet (21-inch): ETSI 300 119-3
Weight (empty cabinet) 45 kg
Dimensions (W x D x H) 600 mm x 300 mm x 2200 mm
Installation dimensions of the
cabinet top
Installation interface
l Hole positions: 413 mm x 200 mm (W x D)
l Nut specifications: four M8 nuts
Installation dimensions of the
cabinet bottom
Installation interface
l Hole positions: 413 mm x 187 mm (W x D)
l Bolt specifications: four M12 expansion bolts
Distance between mounting bar
holes
1 SU = 25 mm. (SU: System Unit.)
Available space 83 SU
Angle opening width 500 mm
Fixing centres 515 mm
Distance between the
installation surface of the
mounting bar and the inner side
of the air filter on the cabinet
front door
47 mm
NOTE
For cabinet power specifications, see relevant PDB specification requirements.
1.1.3 Configuration (MA5600T ETSI subrack)
The N63E-22 cabinet adopts the DC power. This topic describes the MA5600T ETSI subrack
configuration of the N63E-22 cabinet, and lists the maximum number of subscribers of the
cabinet.
The N63E-22 cabinet has the following configurations:
l Configuration of one ETSI subrack
l Configuration of two ETSI subracks
l Configuration of one ETSI subrack and one SPL subrack
l Configuration of the OLT and OLS
