Indicator
Indicato
r
Name Color Status Meaning
RUN
ALM
Running
status
indicator
Red Blinking The board enters the APP
start phase during the
board startup
Green Blinking quickly (on
for 0.25 s and off for
0.25 s repeatedly)
The board enters the phase
of communication with the
control board during its
startup
Green Blinking slowly (on
for 1 s and off for 1 s
repeatedly)
The board works in the
normal state
Orange Blinking The board generates a
recoverable alarms, for
example, a high-
temperature alarm
Red On The board is faulty
ACT Active
indicator
Green On This board is active
Green Blinking This board works in the
load-balancing mode
- Off This board is standby
LINK/A
CT
Optical
port
indicator
Green On A connection is set up on
the port
Green Blinking Data is being transmitted
- Off No connection is set up on
the port
MODE Optical
port mode
indicator
Green On Port is working in the
appropriate mode
- Off Port is not working in the
appropriate mode
3.13 Ethernet Service Access Board (ETH)
Ethernet service access boards provide Ethernet service cascading or upstream transmission,
which does not support user access and user management.
3.13.1 Ethernet Service Access Boards Comparison
Ethernet service access boards include H801ETHA and H801ETHB.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
342
