Front Panel Port
3V3 DC
input port
Connected to
the DC PDU
Indicator
Indicato
r
Name Color Status Meaning
PWR0 The power
board
indicator
Green On The power board works
properly
- Off The power board is faulty
3.12 SPU Board
SPU is a service processing board.
3.12.1 Comparison Between SPU Service Processing Boards
For the functions and specifications supported by the H801SPUB board, see "H801SPUB-
MPLS service processing unit board". The following table lists the functions and
specifications supported by other SPU service processing boards.
In the following table, "Yes" indicates "supported" and "No" indicates "not supported".
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
323
