Huawei SmartAX MA5600T Hardware Description

Table 1-8 Dimensions and weight of the N66E-22 cabinet
Specification Value
Standard Compliance IEC cabinet (19-inch): IEC 60297-3
Weight (Empty Cabinet) 73 kg
Dimensions (W x D x H) 600 mm x 600 mm x 2200 mm
Installation Dimensions of the Cabinet
Top
Installation interface
l Hole positions: 450 mm x 400 mm (W x
D)
l Nut specifications: six M8 nuts
Installation Dimensions of the Cabinet
Bottom
Installation interface
l Hole positions: 413 mm x 487 mm (W x
D)
l Bolt specifications: four M12 expansion
bolts
Distance Between Mounting Bar Holes 1 U = 44.45 mm
Available Space 46 U
Angle Opening Width 450 mm
Fixing Centres 465 mm
Distance Between the Installation Surface
of the Mounting Bar and the Inner Side of
the Cabinet Front Door
192 mm
NOTE
For cabinet power specifications, see relevant PDB specification requirements.
1.3.3 Configuration
The N66E-22 cabinet adopts the DC power. This topic describes the service subrack
configuration, maximum number of subscribers and maximum power consumption of the
N66E-22 cabinet.
Figure 1-50 shows the configuration of the N66E-22 cabinet installed with two service
shelves.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
1 Cabinet
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
58
