Board Power Consumption Maximum Frame Size
H801FCBI
(MA5603T)
l Static: 16 W
l Maximum: 67 W
-
H801FMCA
l Static: 30 W
l Maximum: 72 W
-
H831FCBB
l Static: 4 W
l Maximum: 39 W
-
Environment monitoring board
H801ESCA
l Static: 4 W
l Maximum: related to the connected
sensor
-
Daughter board
H801CKMC
l Static: 4 W (with H801SCUN)
l Maximum: 4 W (with H801SCUN)
-
H801CKMD
l Static: 6 W (with H802SCUN)
l Maximum: 7 W (with H802SCUN)
-
H801FLBA
l Static: 3 W (with H801SCUN)
l Maximum: 4 W (with H801SCUN)
-
H801M2XA
l Static: 25 W (with H802SCUN)
l Maximum: 25 W (with
H802SCUN)
-
3.4 Board Configuration(MA5600T/MA5603T)
This topic describes the type, name, slot and mapping of the boards supported by the
MA5600T/MA5603T.
NOTE
l This manual describes the supply of boards supported by the product. However, the availability of
the boards is subject to the PCNs. For the availability of the boards, contact product mangers at
Huawei representative offices.
l The MA5600T supports two service subracks: ETSI and IEC. The ETSI service subrack has two
more slots for service boards than the IEC service subrack, but they two support the same types of
boards.
l In the table, "Yes" indicates "supported" and "No" indicates "not supported".
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
183
