MA5623AR supports automatic setting the fan speed, the fan speed is automatically adjusted
according to the temperature detected by the temperature sensor configured on the control
board.
The fans of the MA5623AR support alarm report when the fan is blocked.
2.5 MA5603T Chassis Description
This topic describes the chassis and fan tray of the MA5603T.
2.5.1 Appearance
The MA5603T has a fan tray at the left. The subrack is installed in the cabinet through the
mounting brackets.
Figure 2-19 Appearance of the MA5603T chassis(xDSL)
Fan tray
Air filter
Cable teeth
Figure 2-20 Appearance of the MA5603T chassis(GPON)
Fan tray
Air filter
Cable teech
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
2 Subrack and Chassis
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
115
