Pin Assignment
120-Ohm Cable 75-Ohm Cable
Connector Pin Color Relation Core No.
X1.1 Orange Twisted pair W1
X1.2 White
X1.4 Blue Twisted pair W2
X1.5 White
X1.3 Green Twisted pair W3
X1.6 White
X1.7 White Twisted pair W4
X1.8 Brown
Specification
Item
Specification
Cable 120 ohm To 75 ohm Clock Cable
Connector X1
type
Network Interface Connector,8-Bit 8PIN, Crystal Model Connector
120-ohm cable
type
Twisted-Pair Cable, 120 ohm, SEYVP, 0.4 mm, 26AWG, 4Pairs,
Pantone 430U
75-ohm cable
type
Coaxial Cable, SYV-75-2-2(4.0Z)-1/0.34 mm, OD3.9 mm, Double-
Layer Copper Braid Shielded
5.5 Network Cable
A network cable is used for equipment cascading, communication between the device and the
network, and local maintenance and remote access of the device.
