Figure 3-144 Position of the daughter board on the H80ASHLM board
Table 3-170 describes the daughter board supported by the H80ASHLM board.
Table 3-170 Daughter board supported by the H80ASHLM board
Daughter
Board
Function Remarks
SHUI The functional module of logical
processing is integrated on the daughter
board to support the protocol process
and frame format conversion of the
service data stream.
Mandatory
3.24.5 H802SHGM Board Description
The H802SHGM board is a 32-port SHDSL.bis service board. It works with the SHDSL
transceiver unit-remote (STU-R) to provide 32-channels of SHDSL services.
Functional Specifications
Please refer to "SHDSL Service Board Comparison".
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
760
