Indicato
r
Name Color Status Meaning
Red On The board is faulty
0-47
NOTE
Only
LEDs
with the
even
IDs are
valid
when
the port
is
connect
ed to a
one-
channel
optical
module.
Link status
indicator
Green On The connection is
successful
- Off The connection fails
Green Blinking Data is being transmitted
3.17.4 H802OPGE Board Description
The H802OPGE board is a 48-port GE/FE Optical interface board, providing Ethernet optical
access and cascading. It supports up to 48 channels of GE/FE P2P access services.
Functional Specifications
Please refer to "P2P Interface Board Comparison".
When you use H802OPGE boards to replace H802OPGD boards that are bound together, pay
attention to the following items:
l For V800R013C00 or earlier versions, you need to remove the 2 H802OPGD boards that
are bound together and then replace them with H802OPGE boards. Note that the
H802OPGD board and the H802OPGE board cannot be installed in the 2 slots (that are
bound together) at the same time.
l For V800R013C10 or later versions, you need to remove one of the 2 H802OPGD
boards (that are bound together) and then install 1 H802OPGE board. After the
H802OPGE board starts up and functions normally, replace another H802OPGD board.
Technical Specifications
Please refer to "Power Consumption and Maximum Frame Size of Boards".
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
412
