NOTE
l The filled holes are for floating nuts to fasten subracks.
l For the I-type or C3-type PDU, use installation holes 79 and 82; for the B-type PDU, use installation
holes 79 and 81.
l The OFMS-1*8, FTU, and S2318 shown in Figure 1-6 are required when the cabinet functions as a
master cabinet and they need to be installed onsite. For details, see iManager N2510 Line Assurance
System.
1.1.4 Configuration (MA5608T)
The N63E-22 cabinet adopts the DC power. This topic describes the MA5608T configuration
of the N63E-22 cabinet, and lists the maximum number of chassises of the cabinet.
The N63E-22 cabinet has the following configurations:
l Configuration of one MA5608T
l Configuration of two MA5608T
Configuration of One MA5608T
Figure 1-7 shows the configuration of the N63E-22 cabinet installed with one MA5608T.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
1 Cabinet
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
14
