3.21.16 H807ADPM Board Description
The H807ADPM board is a 64-port ADSL2+ over POTS Service Board. It works with the
ADSL terminal unit-remote end (ATU-R) through the ADSL2+ port to access 64 channels of
ADSL2+ service.
Functional Specifications
Please refer to "64-Channel ADSL2+ Service Board Comparison".
Technical Specifications
Please refer to "Power Consumption and Maximum Frame Size of Boards".
